12V 60A Fast Smart Charger For Lead Acid / AGM / GEL Battery 2 Years Warranty

12V 60A Fast Smart Charger For Lead Acid / AGM / GEL Battery 2 Years Warranty

  • 12V 60A Fast Smart Charger For Lead Acid / AGM / GEL Battery 2 Years Warranty
  • 12V 60A Fast Smart Charger For Lead Acid / AGM / GEL Battery 2 Years Warranty
  • 12V 60A Fast Smart Charger For Lead Acid / AGM / GEL Battery 2 Years Warranty
  • 12V 60A Fast Smart Charger For Lead Acid / AGM / GEL Battery 2 Years Warranty
  • 12V 60A Fast Smart Charger For Lead Acid / AGM / GEL Battery 2 Years Warranty
12V 60A Fast Smart Charger For Lead Acid / AGM / GEL Battery 2 Years Warranty
Product Details:
Place of Origin: CHINA
Brand Name: VLDL
Certification: CE, ROHS
Model Number: VL1260
Payment & Shipping Terms:
Minimum Order Quantity: 1 pcs
Price: Negotiable
Packaging Details: 4pcs/carton
Delivery Time: 7-10 days
Payment Terms: TT, Paypal
Supply Ability: 3,000pcs/month
Contact Now
Detailed Product Description
Case: Aluminum Dimensions: 260×150×90 Mm
G.W: 5.0 KG Input Voltage: 110 Or 230 Vac
Max Charging: 14.7V 60A Charge Battery Type: 12V Lead-acid Battery
Applied To EV: E-cars, E-golf Cars, E-forklift Charge Stages: Pre-charge, CC, CV And Floating
Manufacturer: Danl New Energy Co., LTD Warranty: 2 Years
High Light:

constant voltage battery charger

,

battery trickle charger

Fast charger 12V 60A, smart charging for lead acid / AGM / GEL battery, small aluminum case



Brief Descriptions:

Fast battery charger 12V 60A is designed for lead acid (AGM, GEL, SMF) battery powered electric cars or boat appliecation, input 110 or 230Vac and rated output voltatge is 12V 60A. Smart max charging voltage is 14.4V or 14.7V for lead acid (sealed, AGM) type batteries. MCU coutrolled and intelligent 4 steps charging with pre-charge, CC, CV and floating or automatic cut-off, this charger will charge your electric vehicles very fast, with high efficiency and pretect your battery life maximumly. LCD display for charging voltage, current, capacity rate, error, etc.



12V 60A Fast Smart Charger For Lead Acid / AGM / GEL Battery 2 Years Warranty 0



Features:

◆ Advanced high frequency switching mode power supply technology.

◆ DC output isolated from AC input.

◆ Auto worldwide Input 110 / 240Vac(90 ~ 264Vac) with PFC, 50Hz ~ 60Hz.

◆ Charging parameters are insensitive to the AC input line voltage variations.

◆ Completely automatic battery charging: Pre - charging, CC, CV, Absorption, Float or Cut - off.

◆ 2 LEDs: LED1 Red (power on), LED2 Red/green (charging/full)..

◆ Possibility to customize charging curve for request.

◆ Protections: Short circuit, Over-voltage, Over-temperature, Reverse Polarity.

◆ Efficiency > 95%.

◆ Forced ventilation with fans.

◆ 100% full load burn-in test.

◆ Aluminum casing, light weight, portable, on-board.



Technical Specs.:

1) Dimensions(LxWxH): 260 × 150 × 90 MM

2) Net weight: 4.5 KG

3) Max charging voltage(CV): 14.4 / 14.7 volt

4) Floating voltage: 13.5V

5) Max output current (CC): 60 amps

6) Charging method: pre-charge, CC, CV, floating / trickle or shut off

7) AC input voltage: 110 or 230Vac

8) AC input freq.: 50 / 60 Hz

9) AC plug: US, EU, UK etc.

10) Output connector type: Clips, Anderson etc.

11) Enclosure: Aluminum



Output series: 1,200W      Size: 260×150×90 mm       Net weight: 4.5 KG
Input Model Apply to battery types Floating V CV (V) CC (A) Switching



AC Input:

110 / 230V



Frequency:

47~63HZ



VL1260L 12V LiFePO4 Battery   14.6V 60A CC5~8%
VL1260 12V Lead-acid Battery 13.5V 14.7V 60A CC20%
VL1460 14V AGM Battery 13.5V 14.4V 60A CC20%
VL1660L 16V LiFePO4 Battery   18.2V 60A CC5~8%
VL2435LM 24V Li-MnO2 Battery   29.4V 35A CC5~8%
VL2435L 24V LiFePO4 Battery   29.2V 35A CC5~8%
VL2435 24V Lead-acid Battery 27.6V 29.4V 35A CC20%
VL3620LM 36V Li-MnO2 Battery   42V 20A CC5~8%
VL3620L 36V LiFePO4 Battery   43.8V 20A CC5~8%
VL3620 36V Lead-acid Battery 41.4V 44.1V 20A CC20%
VL4818LM 48V Li-MnO2 Battery   54.6V 18A CC5~8%
VL4818L 48V LiFePO4 Battery   43.8V 18A CC5~8%
VL4818 48V Lead-acid Battery 55.2V 58.8V 18A CC20%
VL6015L 60V LiFePO4 Battery   73V 15A CC5~8%
VL6015 60V Lead-acid Battery 67.5V 73.5V 15A CC20%
VL7213L 72V LiFePO4 Battery   87.6V 13A CC5~8%
VL7213 72V Lead-acid Battery 81V 88.2V 13A CC20%
  VL8411L 84V LiFePO4 Battery   102.2V 11A CC5~8%
  VL8411 84V Lead-acid Battery 94.5V 102.9V 11A CC20%
  VL9610L 96V LiFePO4 Battery   116.8V 10A CC5~8%
  VL9610 96V Lead-acid Battery 108V 117.6V 10A CC20%
Note: customized input / output / plug type / connectors are available.

Battery Knowledge



Q. What do the abbreviations MF, GEL and AGM mean?
A. Gel, AGM, Vlies, MF, Calcium/Calcium and Hybrid are abbreviations for different types of lead-acid batteries.



Q. What do the abbreviations LiFePO4, Li-ion, Li-MnO2 and LiCoO2 mean?

A. LiFePO4, Li-ion, Li-MnO2 and LiCoO2 are abbreviations for different types of lithium batteries, that means there batteries using different cathode materials. Different batteries have different charging voltages.



Battery Charger Knowledge



Q. What charger should I choose?
A. It depends on the type of battery, the capacity of the battery, the application and how much you are prepared to spend. Just tell us your battery information, DANL battery charger engineer will recommend the most suitable charger for you or customized by your batteries and applications.



Q. Can I charge several batteries in parallel?
A. The charger has no problem whatsoever of charging or maintaining several batteries, as long as they are connected in parallel. The charger sees the parallel connected batteries as one large battery. The sum of the capacity has to be below the recommendation for your model. Please note that there could be a high current between batteries when they are connected together, i.e. use high quality wiring.



Q. Can you really connect and then forget about the charger?
A. That depends on your batteries state and charger’s type. Danl lead-acid battery chargers have maintenance mode(floating mode), charger charges with very small current at this mode, so you can forget about the charger but not exceed 24 hours. If your battery is lithium type and without BMS system, please don’t forget the charger.



About DANL Company



Q. Are you a factory or trading company?

A. Danl is battery charger factory and we found in 2008. We have being in switching mode power supply and charger industrial for 15 years and have 10 years of exporting experience to worldwide especially to the high lever market of North America and Euro countries.



Q. What's about the warranty for Danl battery chargers?

Danl promises that we provide full 2 years warranty for our battery chargers. No return for faulty battery chargers firstly, we send you new replacing chargers firstly. Danl adopts latest ATE Automatic Battery Charger Testing System to test all of our battery chargers before shipping, guaranteeing extremely low rate of failure. So we have confidence to provide 2 years warranty.



Q. Do you accept OEM order?

A. Yes, we do. Danl provides OEM, ODM service. Please just tell us your project and we will provide a full charging solution for you, for example, your customized electric vehicles, sun-powered stations, racing batteries, on-board charging, etc.



Q. What is about the lead time for an order?

A. Normally, lead time is 7 days. If need large quantity, say 500 to 1000pcs, it will take about 15 days. If you need ODM charging solution, lead time depends on technical request, often it needs about 30 days.



Q. What certification do you have?

A. We have CE, RoHS, CB currently. We will add and pass the test of certificate which applied in your country.



Q. Why choose your smart battery chargers?

A. Because our battery chargers have high quality but reasonable factory price. First, we do not use cheap and unreliable components to save cost like other charger factories who have very cheap price. Second, we use latest ATE smart battery charger test and aging system and guarantee the quality of every battery chargers.
