Automatic Charging Electric Scooter Lithium Battery Charger With XLR Output Connector

Automatic Charging Electric Scooter Lithium Battery Charger With XLR Output Connector

    • Automatic Charging Electric Scooter Lithium Battery Charger With XLR Output Connector
    • Automatic Charging Electric Scooter Lithium Battery Charger With XLR Output Connector
    • Automatic Charging Electric Scooter Lithium Battery Charger With XLR Output Connector
    • Automatic Charging Electric Scooter Lithium Battery Charger With XLR Output Connector
  • Automatic Charging Electric Scooter Lithium Battery Charger With XLR Output Connector

    Product Details:

    Place of Origin: China
    Brand Name: VLDL
    Certification: CE, ROHS
    Model Number: VL4802L

    Payment & Shipping Terms:

    Minimum Order Quantity: 12 pcs
    Price: Negotiable
    Packaging Details: Carton, 12pcs / carton
    Payment Terms: T/T, Paypal
    Supply Ability: 100000pcs/month
    Contact Now
    Detailed Product Description
    Material: Aluminum Size: 135*90*50 MM
    Net Weight: 0.8 KG Color: Silver Or Black
    Applied To: 48V Lithium Or SLA Battery Input Volt: 110 - 240Vac
    Output: Rated 48V 2A Max 58.4V Applied To EV: Electric Scooters / Motorcycles
    Output Power: 120W

    Automatic Charging Electric Scooter Lithium Battery Charger With XLR Output Connector

    Brief Description:

    58.4V 2A Electric scooter lithium battery charger, worldwide 110 - 230V input, 4 step charging for lithium or lead acid battery. Max 54.6V / 58.4V / 58.8V smart charging voltage for 48V SLA, AGM, GEL, lithium (LiFePO4, Li-ion, LiMO2) battery packs. Automatic 4 steps transition of pre-charge, CC, CV and floating / trickle or shut off. Aluminum housing, light weight and portable. 2 years warranty, high quality.

    Features:

    ◆ Advanced high frequency switching mode power supply technology.
    ◆ DC output isolated from AC input.
    ◆ Auto worldwide Input 110 / 230Vac (90 ~ 264Vac), 50Hz~60Hz.
    ◆ Charging parameters are insensitive to the AC input line voltage variations.
    ◆ Completely automatic battery charging: Pre-charging, CC, CV, Absorption, Float or Cut-off.
    ◆ 2 LEDs: LED1 Red (power on), LED2 Red / green (charging/full)..
    ◆ Possibility to customize charging curve for request.
    ◆ Protections: Short circuit, Over-voltage, Over-temperature, Reverse Polarity.
    ◆ Efficiency > 95%.
    ◆ Forced ventilation with fans.
    ◆ 100% full load burn-in test.
    ◆ Aluminum casing, light weight, portable.

    Technical Specs.:

    1) Dimensions(LxWxH): 135 x 90 x 50 mm
    2) Net weight: 0.8 KG
    3) Max charging voltage(CV): 58.4 volts
    4) Floating voltage: customized
    5) Max output current (CC): 2 amps
    6) Charging method: pre-charge, CC, CV, floating / trickle or shut off
    7) AC input voltage: 110 - 240Vac worldwide
    8) AC input freq.: 50 / 60 Hz
    9) AC plug: customized by users country
    10) Output connector type: customized by applications
    11) Enclosure: Aluminum

    Output series: 120W     Size: 135×90×50 mm     Net weight: 0.8 KG
    InputModelApply to battery typesFloating VCV (V)CC (A)Switching

    AC Input:

    85~264V



    Frequency:

    47~63HZ



    VL1206L12V LiFePO4 Battery 14.6V6ACC5~8%
    VL120612V Lead-acid Battery13.5V14.7V6ACC20%
    VL2404LM24V Li-MnO2 Battery 29.4V4ACC5~8%
    VL240424V Lead-acid Battery27.6V29.4V4ACC20%
    VL3603L36V Li-MnO2 Battery 42V3ACC5~8%
    VL360236V Lead-acid Battery41.4V44.1V2ACC20%
    VL4802LM48V Li-MnO2 Battery 54.6V2ACC5~8%
    VL480248V Lead-acid Battery55.2V58.8V2ACC20%
    Note: customized input / output / plug type / connectors are available.


    Quality Control

    We have passed Quality Management ISO 9001:2015 and Environmental Management ISO 14001:2015. We control our quality as following 6 steps:

    Step 1 Using Famous Brand Components: Only use famous brand and high quality components and choose suppliers with certifications. Guarantee no low quality components get into our warehouse.

    Step 2 Inspecting Components: Inspect every batch of incoming components.

    Step 3 Qualified Workers Assembling: 2 year qualified workers assemble the battery chargers, high efficiency and low failure rate.

    Step 4 Smart Aging System: Using smart aging system to do burn-in test with full load for at least two hours. This system will age battery chargers automatically after setting in computer and record every aging information. Guarantee every battery charger’s components under the good condition.

    Step 5 Latest ATE Battery Charger Test System: At last, we do final test by our latest ATE Battery Charger Test System before packing. This system will do more than 10 performances automatic testing and check all functions automatically, recording test data with very fast and precise way, tracking test result, reading, comparing and filing all data, easy to control. Every battery charger has an unique tracking code, when there is a fault on battery charger, we just scan the code and track its manufacturing information.

    Step 6 Random Test Before Shipping: Before shipping, we will choose two chargers randomly and test again. This shipment can be released for shipping if there is no problem at random test.

    Packing details:

    Automatic Charging Electric Scooter Lithium Battery Charger With XLR Output Connector
    Automatic Charging Electric Scooter Lithium Battery Charger With XLR Output Connector
