AGM Battery Charger 12V 6A , 110 - 230Vac Lead Acid Battery Charger With Clips Connector

AGM Battery Charger 12V 6A , 110 - 230Vac Lead Acid Battery Charger With Clips Connector

  • AGM Battery Charger 12V 6A , 110 - 230Vac Lead Acid Battery Charger With Clips Connector
  • AGM Battery Charger 12V 6A , 110 - 230Vac Lead Acid Battery Charger With Clips Connector
  • AGM Battery Charger 12V 6A , 110 - 230Vac Lead Acid Battery Charger With Clips Connector
  • AGM Battery Charger 12V 6A , 110 - 230Vac Lead Acid Battery Charger With Clips Connector
AGM Battery Charger 12V 6A , 110 - 230Vac Lead Acid Battery Charger With Clips Connector
Product Details:
Place of Origin: CHINA
Brand Name: VLDL
Certification: CE, ROHS
Model Number: VL1206
Payment & Shipping Terms:
Minimum Order Quantity: 12 pcs
Price: Negotiable
Packaging Details: 12 pcs / carton
Delivery Time: 7 - 10 days
Payment Terms: TT, Paypal
Supply Ability: 1,000 pcs / month
Contact Now
Detailed Product Description
Housing: Aluminum Size: 135*90*50 MM
Net Weight: 0.8 KG Input Voltage: 110 - 230 Vac
Output: Rated 12V 6A, Max 14.4VDC Case Color: Silver Or Black
Output Power: 90W Applied To: 12V AGM Battery
Frequency: 50 / 60 Hz Charge Curve: Pre Charge, CC, CV, Floating / Trickle Or Shut Off
High Light:

car lead acid battery charger

,

constant voltage battery charger

AGM Battery Charger 12V 6A , 110 - 230Vac Lead Acid Battery Charger With Clips Connector

Brief Description:

Sealed lead acid battery charger 12 volts 6 amps, input with worldwide 110 to 230Vac and rated output voltatge is 12V 6A. Smart max charging voltage is 14.7V for SLA type batteries or AGM batteries. Intelligent 4 stages charging with pre-charge, CC, CV and floating / trickle steps, this charger will charge your battery powered electric vehicles very fast, with high efficiency and pretect your battery life maximumly. High quality, factory price and 2 years warranty.


Features

1) Optional charging methods: Lithium or SLA / AGM batteries.
2) Advanced high frequency switching mode power supply technology.
3) DC output isolated from AC input.
4) Automatic worldwide Input 110 / 230Vac (90 ~ 264Vac), 50Hz ~ 60Hz.
5) Charging parameters are insensitive to the AC input line voltage variations.
6) Completely automatic 4 steps charge: pre-charge, CC, CV, floating/trickle or shut-off.
7) Protections: Short circuit, Over - voltage, Over - temperature, Reverse Polarity.
8) Aluminum casing, light weight, portable.
9) 100% full load burn-in test.
10) 2 years warranty.

Technical Specs.:
1) Dimensions(LxWxH): 135 x 90 x 50 mm
2) Net weight: 0.8 KG
3) Max charging voltage(CV): 14.4 volt
4) Floating voltage: customized
5) Max output current (CC): 6 amps
6) Charging method: pre-charge, CC, CV, floating / trickle or shut off
7) AC input voltage: 110 - 240Vac
8) AC input freq.: 50 / 60 Hz
9) AC plug: customized by users country
10) Output connector type: customized by applications
11) Enclosure: Aluminum


Output series: 120W     Size: 135×90×50 mm     Net weight: 0.8 KG
InputModelApply to battery typesFloating VCV (V)CC (A)Switching

AC Input:

85~264V



Frequency:

47~63HZ



VL1206L12V LiFePO4 Battery 14.6V6ACC5~8%
VL120612V Lead-acid Battery13.5V14.7V6ACC20%
VL2404LM24V Li-MnO2 Battery 29.4V4ACC5~8%
VL240424V Lead-acid Battery27.6V29.4V4ACC20%
VL3603L36V Li-MnO2 Battery 42V3ACC5~8%
VL36025L36V Li-MnO2 Battery 42V2.5ACC5~8%
VL360236V Lead-acid Battery41.4V44.1V2ACC20%
VL4802LM48V Li-MnO2 Battery 54.6V2ACC5~8%
VL480248V Lead-acid Battery55.2V58.8V2ACC20%
Note: customized input / output / plug type / connectors are available.



Battery Charger Knowledge


Q. What charger should I choose?
A. It depends on the type of battery, the capacity of the battery, the application and how much you are prepared to spend. Just tell us your battery information, DANL battery charger engineer will recommend the most suitable charger for you or customized by your batteries and applications.

Q. Can I charge several batteries in parallel?
A. The charger has no problem whatsoever of charging or maintaining several batteries, as long as they are connected in parallel. The charger sees the parallel connected batteries as one large battery. The sum of the capacity has to be below the recommendation for your model. Please note that there could be a high current between batteries when they are connected together, i.e. use high quality wiring.

Q. Can you really connect and then forget about the charger?
A. That depends on your batteries state and charger’s type. Danl lead-acid battery chargers have maintenance mode(floating mode), charger charges with very small current at this mode, so you can forget about the charger but not exceed 24 hours. If your battery is lithium type and without BMS system, please don’t forget the charger.


About DANL Company


Q. Are you a factory or trading company?
A. Danl is battery charger factory and we found in 2008. We have being in switching mode power supply and charger industrial for 15 years and have 10 years of exporting experience to worldwide especially to the high lever market of North America and Euro countries.

Q. What's about the warranty for Danl battery chargers?
Danl promises that we provide full 2 years warranty for our battery chargers. No return for faulty battery chargers firstly, we send you new replacing chargers firstly. Danl adopts latest ATE Automatic Battery Charger Testing System to test all of our battery chargers before shipping, guaranteeing extremely low rate of failure. So we have confidence to provide 2 years warranty.

Q. Do you accept OEM order?
A. Yes, we do. Danl provides OEM, ODM service. Please just tell us your project and we will provide a full charging solution for you, for example, your customized electric vehicles, sun-powered stations, racing batteries, on-board charging, etc.

Q. What is about the lead time for an order?
A. Normally, lead time is 7 days. If need large quantity, say 500 to 1000pcs, it will take about 15 days. If you need ODM charging solution, lead time depends on technical request, often it needs about 30 days.

Q. What certification do you have?
A. We have CE, RoHS, CB currently. We will add and pass the test of certificate which applied in your country.

Q. Why choose your smart battery chargers?
A. Because our battery chargers have high quality but reasonable factory price. First, we do not use cheap and unreliable components to save cost like other charger factories who have very cheap price. Second, we use latest ATE smart battery charger test and aging system and guarantee the quality of every battery chargers.

12V 20A sealed lead acid battery charger with max 14.7V CV and 20 amps CC charging, for Euro and US market
