25 Amps 1500 Watts Lithium Battery Charger , 48 Volts Smart Li Charger For Electric Vehicles

25 Amps 1500 Watts Lithium Battery Charger , 48 Volts Smart Li Charger For Electric Vehicles

Brief Description:

High power 1500W 48 volt 25 amps automatic battery charger for lithium battery pack. Smart charging with 4 steps for lithium batteries, PFC charger with universal 110 or 240 Vac, it is designed for electric motorcycles, electric floor sweepers and electric cars, smart charge LiFePO4 / Li ion / LiMO2 batteries. Charging with 54.6 Vdc or 58.4 Vdc 25 amps, max 1500 watts output power. Smart 4 steps charging: pre charge, CC, CV and automatic shut off and maximumly protecting your expensive lithium batteries. Small size, portable for electric scooters, electric bikes and electric motorcycles. We can customize input and output by your battery specifications. Small size, light weigh and portable.

Features:

◆ Advanced high frequency switching mode power supply technology.

◆ DC output isolated from AC input.

◆ Auto worldwide Input 110 / 230Vac(90 ~ 264Vac), 50Hz ~ 60Hz.

◆ Charging parameters are insensitive to the AC input line voltage variations.

◆ Completely automatic battery charging: Pre charging, CC, CV, Absorption, Float or Cut - off.

◆ 2 LEDs: LED1 Red (power on), LED2 Red / green (charging/full)..

◆ Possibility to customize charging curve for request.

◆ Protections: short circuit, over voltage, over temperature, reverse Polarity.

◆ Efficiency > 95%.

◆ Forced ventilation with fans.

◆ 100% full load burn-in test.

◆ Aluminum casing, light weight, portable.

Technical Specs.:

1) Dimensions(LxWxH): 300 x 150 x 90 mm

2) Net weight: 5.5 KG

3) Max charging voltage(CV): 54.6 / 58.4 volt

4) Floating voltage: customized

5) Max output current (CC): 25 amps

6) Charging method: automatic pre-charge, CC, CV, floating / trickle or shut off

7) AC input voltage: 110 or 240Vac

8) AC input freq.: 50 / 60 Hz

9) AC plug: customized by user’s country

10) Output connector type: customized by applications

11) Enclosure: Aluminum

Additional information

DANL New Energy is a 15 years battery chargers manufacturer / factory / supplier. We design and manufacture all by ourselves. We control the quality with high level and have been updating our technology to the latest. We promise 2 years full warranty for all of our battery chargers. Best quality and factory price are worth to be your sincere supplier of battery charger market.
