2000 Watts Power Lithium Battery Smart Charger For Electric Cars Or Electric Forklifts

2000 Watts Power Lithium Battery Smart Charger For Electric Cars Or Electric Forklifts

  • 2000 Watts Power Lithium Battery Smart Charger For Electric Cars Or Electric Forklifts
  • 2000 Watts Power Lithium Battery Smart Charger For Electric Cars Or Electric Forklifts
  • 2000 Watts Power Lithium Battery Smart Charger For Electric Cars Or Electric Forklifts
  • 2000 Watts Power Lithium Battery Smart Charger For Electric Cars Or Electric Forklifts
2000 Watts Power Lithium Battery Smart Charger For Electric Cars Or Electric Forklifts
Product Details:
Place of Origin: CHINA
Brand Name: VLDL
Certification: CE, ROHS
Model Number: VL4830 / VL4830L
Payment & Shipping Terms:
Minimum Order Quantity: 4 pcs
Price: Negotiable
Packaging Details: 4 pcs / carton
Delivery Time: 7-10 days
Payment Terms: TT, Paypal
Supply Ability: 1000pcs/month
Contact Now
Detailed Product Description
Case Material: Aluminum Size: 330*150*90 Mm
Net Weight: 6.5 KG Input Volt: 110 Or 230 Vac
Output: 48V 30A, Max 54.6V / 58.4V Applied Battery: LiFePO4, LiMO2, Li - Ion, Li Polymer
Color: Black Or Silver Output Power: 2000W Max
Charging EV: Electric Floor Sweeper, E-cars, E-forklifts
High Light:

li ion battery pack charger

,

lithium battery smart charger

2000 Watts Power Lithium Battery Smart Charger For Electric Cars Or Electric Forklifts



Brief Description:



48 volt 30 amps automatic battery charger for lithium battery pack. 2000 watts high power output power. Smart charging with 4 steps for lithium batteries, input 110 or 240 Vac, it is designed for electric cars and electric forklifts, smart charge LiFePO4 / Li ion / LiMO2 batteries. Charging with 54.6 Vdc or 58.4 Vdc 30 amps, max 2000 watts output power. Smart 4 steps charging: pre charge, CC, CV and automatic shut off and maximumly protecting your expensive lithium batteries. Small size, portable for electric scooters, electric bikes and electric motorcycles. We can customize input and output by your battery specifications. Small size, light weigh and portable.



Features:



◆ Advanced high frequency switching mode power supply technology.

◆ DC output isolated from AC input.

◆ Auto worldwide Input 110 or 230Vac, 50Hz ~ 60Hz.

◆ Charging parameters are insensitive to the AC input line voltage variations.

◆ Completely automatic battery charging: Pre charging, CC, CV, Absorption, Float / trickle or Cut - off.

◆ 2 LEDs: LED1 Red (power on), LED2 Red / green (charging/full)..

◆ Possibility to customize charging curve for request.

◆ Protections: short circuit, over voltage, over temperature, reverse Polarity.

◆ Efficiency > 95%.

◆ Forced ventilation with fans.

◆ 100% full load burn-in test.

◆ Aluminum casing, light weight, portable.



Technical Specs.:



1) Dimensions(LxWxH): 330 x 150 x 90 mm

2) Net weight: 6.5 KG

3) Max charging voltage(CV): 54.6 / 58.4 volt

4) Floating voltage: customized

5) Max output current (CC): 30 amps

6) Charging method: automatic pre-charge, CC, CV, floating / trickle or shut off

7) AC input voltage: 110 or 240Vac

8) AC input freq.: 50 / 60 Hz

9) AC plug: customized by users country

10) Output connector type: customized by applications

11) Enclosure: Aluminum



Output series: 2,000W      Size: 330×150×90 mm      Net weight: 6.5 KG
Input Model Apply to battery types Floating V CV (V) CC (A) Switching



AC Input:

110 / 230V



Frequency:

47~63HZ



VL12100L 12V LiFePO4 Battery   14.6V 100A CC5~8%
VL12100 12V Lead-acid Battery 13.5V 14.7V 100A CC20%
VL14100 14V AGM Battery 13.5V 14.4V 100A CC20%
VL16100L 16V LiFePO4 Battery   18.2V 100A CC5~8%
VL2460LM 24V Li-MnO2 Battery   29.4V 60A CC5~8%
VL2460L 24V LiFePO4 Battery   29.2V 60A CC5~8%
VL2460 24V Lead-acid Battery 27.6V 29.4V 60A CC20%
VL3640LM 36V Li-MnO2 Battery   42V 40A CC5~8%
VL3640L 36V LiFePO4 Battery   43.8V 40A CC5~8%
VL3640 36V Lead-acid Battery 41.4V 44.1V 40A CC20%
VL4830LM 48V Li-MnO2 Battery   54.6V 30A CC5~8%
VL4830L 48V LiFePO4 Battery   43.8V 30A CC5~8%
VL4830 48V Lead-acid Battery 55.2V 58.8V 30A CC20%
VL6025L 60V LiFePO4 Battery   73V 25A CC5~8%
VL6025 60V Lead-acid Battery 67.5V 73.5V 25A CC20%
VL7220L 72V LiFePO4 Battery   87.6V 20A CC5~8%
VL7220 72V Lead-acid Battery 81V 88.2V 20A CC20%
  VL8418L 84V LiFePO4 Battery   102.2V 18A CC5~8%
  VL8418 84V Lead-acid Battery 94.5V 102.9V 18A CC20%
  VL9616L 96V LiFePO4 Battery   116.8V 16A CC5~8%
  VL9616 96V Lead-acid Battery 108V 117.6V 16A CC20%
Note: customized input / output / plug type / connectors are available.



Additional information



DANL New Energy is a 15 years battery chargers manufacturer / factory / supplier. We design and manufacture all by ourselves. We control the quality with high level and have been updating our technology to the latest. We promise 2 years full warranty for all of our battery chargers. Best quality and factory price are worth to be your sincere supplier of battery charger market.
